What is High Speed PCB?
A high speed PCB is a printed circuit board that is designed and manufactured to provides high speed data transmission rates. They enable the board to process data quickly while minimizing any potential data transmission errors that may occur. High-speed PCBs are generally composed of specialized materials designed to reduce signal loss between components. These materials also help to reduce production costs and keep the size of these boards compact. Additionally, they come with advanced practices in routing and design that minimize the size of components and increase cycle times. These features make them ideal for communication applications, wherein voltage rises or drops in a short time period.
Why Use a High Speed PCB?
High speed PCBs are essential for any communication project that requires digital circuit speed above 45MHZ. Our specialized PCBs are highly resistant to signal interference, and the finely tuned components minimize any errors and maximize data speed.
- High speed data transmission rates
- Minimized signal interference, Enhanced signal integrity
- Minimized errors and data transmission errors
- Maximized cycle times
- Reliable grounding and reduced signal distortion
- Lightweight and compact design
- Improved performance and reliability
Materials used to Manufacture High Speed PCB
About the materials used to manufacture high speed PCBs, we use polymer resin with or without fillers, reinforcement, and metal foil from brands like Panasonic, Formosa, and Isola. These materials are able to withstand extreme temperatures and guarantee signal integrity:
- Isola 370HR, I-Speed, I-Tera MT40, MT77
- Rogers 3003, 4000 series
